SMART SERIAL CODE SCANNER FOR SOLAR PANELS
Portable GPS-RTK system for accurate serial code detection and georeferenced data management.
Portable backpack
With GPS RTK + LTE
High-performance barcode scanner
up to 1500 panels/h
The Serials Scanner portable backpack unit integrates a high-performance barcode reader with GPS-RTK and LTE connectivity. Designed for field operators, it enables fast and precise scanning of solar panel serial codes, automatically georeferenced with centimeter-level accuracy. Lightweight, durable, and equipped with long-lasting batteries, the system ensures efficient data collection even in remote areas, seamlessly synchronizing with the web platform for validation, reporting, and analysis.
Accurate Serial Code Mapping
Managing and georeferencing solar panel serial codes is complex and time-consuming. Serials Scanner makes it fast, precise, and reliable.
Structured table with serial numbers, GPS coordinates, accuracy data, and timestamps for easy analysis and reporting.
Vector file showing georeferenced serial codes in UTM coordinates, ideal for CAD integration and technical mapping.
Aerial or drone-based image with serial numbers overlaid on solar panels, providing clear visual validation and mapping.
Web Platform Integration
-
Data Management
Review and validate acquired serial codes with their precise georeferenced positions. -
Analysis & Statistics
Generate plant reports and monitor the progress of field activities in real time. -
Operational Management
Track unit positions on-site in real time and remotely configure each device
Real-Time Validation Panel
This web interface panel lets operators configure plant details, RTK settings, and validation rules. During scanning, each serial number is instantly checked for code length and GPS accuracy. If values fall outside thresholds, the backpack emits a double beep to signal the anomaly, and the serial number is not recorded.
Interactive Map Adjustment Tool
The web platform includes an intuitive tool that allows operators to manually adjust the position of each scanned serial point on the map. This feature ensures maximum accuracy, enabling fine-tuned corrections beyond automatic GPS-RTK data. Users can refine mapping results, validate placements, and guarantee precise documentation for every solar panel.
Portable Backpack Unit
Wearable backpack with high-precision GPS RTK receiver and LTE/3to5G modem.
Powered by commercial lithium battery (>10h, swappable).
Centimeter-Accurate RTK Technology
Reliable positioning for solar panel mapping
RTK (Real-Time Kinematic) technology enhances GPS accuracy by applying real-time corrections, reducing positioning errors to just a few centimeters. When integrated into the Serials Scanner, RTK ensures each scanned solar panel serial code is precisely georeferenced, enabling accurate validation, reporting, and seamless integration into technical maps and monitoring systems.
Elevated Antenna System
Separated from the backpack body and raised above the operator, the antenna guarantees stronger LTE and GPS signals while preserving comfort and ease of movement.
High-Performance Scanner
The barcode scanner ensures fast and precise serial code acquisition in the field. Configurable for continuous or trigger mode, it enables operators to efficiently scan up to 1500 solar panels per hour with maximum accuracy and reliability.
Backpack Scanning Unit
The core backpack unit integrates GPS-RTK, LTE connectivity, and data processing, ensuring reliable serial code acquisition, precise georeferencing, and seamless communication with the web platform.
Specifications
- Dimensions: 250 × 160 × 280 mm + 300 mm (antenna)
- Weight: 2.6 kg (battery included)
- Battery: Commercial lithium battery, 18V 5Ah
- Modem: 3G / 4G / 5G
- SIM: Compatible with any operator
- Barcode Scanner: High-performance industrial grade
- Scanning Capacity (optimal conditions): Up to 1500 panels/hour
Kit include
- Portable backpack unit
- 1 rechargeable battery
- 220V charger
- Carrying case
Advanced Solar Panel Scanning in the Field
Backpack system with GPS-RTK and barcode scanner ensures fast, accurate serial code acquisition and reliable solar panel mapping.
RTK Base Station Accessory
The RTK Base Station provides centimeter-level positioning even without LTE coverage. By generating a local correction signal, it ensures accurate georeferencing in any field condition, extending reliability and performance of the backpack scanning unit.
Specifications
Dimensions: 200 × 200 × 280 mm + tripod
Weight: 2.2 kg (battery included) + tripod
Battery: Commercial lithium drill battery, 18V 5Ah
Modem: 4G
SIM: Compatible with any operator
Request Your Quote Today
Do not hesitate to contact us by email for further details or to request a quotation today.
